Installation Guide - 34mm Round Poles

Installation Instructions –34mm Round Poles

Determine the height at which the pole must be installed.
Mark the drill holes on the wall (one hole per bracket).
Drill using a 5.5 mm masonry bit and insert the wall plugs provided.
Insert the screw so the head sits about 4 mm from the wall.
Mount the wall bracket onto the screw. If loose, remove and tighten the screw for a snug fit.
Add rings (if used) to the pole before mounting it onto the brackets.
Install the pole onto the brackets and secure by driving a chipboard screw through the bottom of the bracket into the pole.
Attach the finials by coating the dowels with wood glue and inserting into the ends of the pole.
